The Roxtec H3 UG™ is a three-part seal for easy installation. The transit has a +3mm tolerance towards the aperture and an indicator showing when a compressed seal is achieved.
- For cables in trefoil formation
- Can be used together with Roxtec UG™ sleeve products
Technical drawings
Installation instructions
Component articles
 UG.jpg)
H3-150 UG INSERTABLE
- Number of cables/pipes 3
- For cable/pipe Ø (mm) 24 - 52
- Aperture dimension Ø (mm) 150 - 153
- Weight (kg) 2.6
- Art. No 155189
H3-200 UG INSERTABLE
- Number of cables/pipes 3
- For cable/pipe Ø (mm) 48 - 68
- Aperture dimension Ø (mm) 200 - 203
- Weight (kg) 4.4
- Art. No 127053
H3-150 UG INSERTABLE WOC
- Number of cables/pipes 3
- For cable/pipe Ø (mm) 24 - 52
- Aperture dimension Ø (mm) 150 - 153
- Weight (kg) 2.3
- Art. No 166396
H3-200 UG INSERTABLE WOC
- Number of cables/pipes 3
- For cable/pipe Ø (mm) 48 - 68
- Aperture dimension Ø (mm) 200 - 203
- Weight (kg) 3.7
- Art. No 164807
| Product | Number of cables/pipes | For cable/pipe Ø (mm) | Aperture dimension Ø (mm) | Weight (kg) | Art. No | |
|---|---|---|---|---|---|---|
| H3 101 (4") UG | 3 | 9 - 33 | 101 - 104 | 1.2 | 224498 | |
| H3 127 (5") UG | 3 | 23 - 43 | 126.5 - 129.5 | 1.9 | 224448 | |
| H3-135 UG | 3 | 23 - 43 | 135 - 138 | 2.2 | 126281 | |
| H3-150 UG | 3 | 24 - 52 | 150 - 153 | 2.5 | 151561 | |
| H3 153 (6") UG | 3 | 24 - 52 | 152.5 - 155.5 | 2.8 | 224470 | |
| H3-185 UG | 3 | 48 - 64 | 185 - 188 | 3.9 | 126283 | |
| H3-200 UG | 3 | 48 - 68 | 200 - 203 | 4.3 | 117842 | |
| H3 201 (8") UG | 3 | 39 - 68 | 201 - 204 | 4.4 | 224483 | |
| H3-150 UG INSERTABLE | 3 | 24 - 52 | 150 - 153 | 2.6 | 155189 | |
| H3-200 UG INSERTABLE | 3 | 48 - 68 | 200 - 203 | 4.4 | 127053 | |
| H3-135 UG WOC | 3 | 23 - 43 | 135 - 138 | 2.3 | 151306 | |
| H3-150 UG WOC | 3 | 24 - 52 | 150 - 153 | 2.6 | 155188 | |
| H3-185 UG WOC | 3 | 48 - 64 | 185 - 188 | 3.5 | 151308 | |
| H3-200 UG WOC | 3 | 48 - 68 | 200 - 203 | 4 | 108697 | |
| H3-150 UG INSERTABLE WOC | 3 | 24 - 52 | 150 - 153 | 2.3 | 166396 | |
| H3-200 UG INSERTABLE WOC | 3 | 48 - 68 | 200 - 203 | 3.7 | 164807 |
