Roxtec GH BG™ FL100 transit

Data sheet (metric)

Use the print button on the page for an optimized print layout.

Transit with wide flange and earthing terminal, for bolting onto uneven structures.

The Roxtec GH BG™ FL100 is a cable and pipe seal for bonding and grounding applications. The rectangular steel frame with the wide flange ensures a tight seal when bolted onto concrete or brick walls/floors. The seal allows for high cable and pipe packing density. The transit can be used with a GE extension frame in galvanized steel to cover the depth of a thick wall. Roxtec EC (electrical continuity) test sticks are available to help indicate the electrical performance of the transit installation.

  • Easy to maintain and inspect
  • Provides built-in spare capacity

Download

Data sheet (metric)
Buy solution

Product characteristics

  • fire rated.svg
    Fire rated
  • ip-ul nema.svg
    IP/UL NEMA
  • electrical saftey.svg
    Electrical safety
  • gas-tight.svg
    Gas-tight

Download

Data sheet (metric)

Page index

Ratings & certificates Installation Seals for your industry Sealing component data Pre-configured transit kits Configure your own transit kit

Ratings & certificates

Certificates are continuously added, renewed and replaced, please visit regularly to ensure compliance.

Fire

  • E/EI rating according to EN 13501
  • F/T rating according to UL 1479

Tightness

  • Gas: 0.1 bar (catastrophic)
  • IP 66/67
  • IP 68

Supports

  • Bonding and grounding

Installation

Structure of installation

  • concrete_icon.svg
    Concrete
  • brick_icon.svg
    Brick

Mounting type

  • bolting.svg
    Bolting

Installation instructions

Installation videos

Cable preparation - BG™ system

Roxtec RM BG™ B system installation

Roxtec sealing system – Guidelines for bolted frames, smooth concrete

Roxtec sealing system – Guidelines for bolted frames, rough concrete

Seals for your industry

Explore the multitude of applications where you can benefit from our solutions.

Sealing component data

Here you find technical information about each specific part of our system.

Accessories

Holder tools

Holder tools
GE extension frame

GE extension frame
Accessories ES and BG

Accessories ES and BG

Rectangular frames

GH BG™ FL100 frame

GH BG™ FL100 frame

Sealing components

RM BG™ module with Multidiameter™

RM BG™ module with Multidiameter™
RM BG™ solid compensation module

RM BG™ solid compensation module
Wedge & Wedge kit

Wedge & Wedge kit
Lubricant

Lubricant
BG™ sealing kit

BG™ sealing kit
Stayplate

Stayplate

Pre-configured transit kits

mm/kg inch/lbs

GH BG B FL 100 6x1/18 GALV

  • Configuration 6 x cables/pipes diameter 0+3.5-16.5mm
    12 x cables/pipes diameter 0+9.5-32.5mm
  • External dimensions WxHxD (mm) 332.5 x 430 x 93.6
  • Aperture dimensions WxH (mm) 148(+5/-5) x 245(+5/-5)
  • Weight (kg)
Add
Remove from cart?

GH BG B FL 100 6x1/19 GALV

  • Configuration 6 x cables/pipes diameter 0+3.5-16.5mm
    8 x cables/pipes diameter 0+10-25mm
    3 x cables/pipes 0+9.5-32.5mm
    2 x cables/pipes 0+28-54mm
  • External dimensions WxHxD (mm) 332.5 x 430 x 93.6
  • Aperture dimensions WxH (mm) 148(+5/-5) x 245(+5/-5)
  • Weight (kg)
Add
Remove from cart?

GH BG B FL 100 6x1/26 GALV

  • Configuration 12 x cables/pipes diameter 0+3.5-16.5mm
    8 x cables/pipes diameter 0+10-25mm
    6 x cables/pipes 0+9.5-32.5mm
  • External dimensions WxHxD (mm) 332.5 x 430 x 93.6
  • Aperture dimensions WxH (mm) 148(+5/-5) x 245(+5/-5)
  • Weight (kg)
Add
Remove from cart?

GH BG B FL 100 6x2/36 GALV

  • Configuration 12 x cables/pipes diameter 0+3.5-16.5mm
    24 x cables/pipes diameter 0+9.5-32.5mm
  • External dimensions WxHxD (mm) 463 x 430 x 93.6
  • Aperture dimensions WxH (mm) 278(+5/-5) x 245(+5/-5)
  • Weight (kg)
Add
Remove from cart?

GH BG B FL 100 6x2/38 GALV

  • Configuration 12 x cables/pipes diameter 0+3.5-16.5mm
    16 x cables/pipes diameter 0+10-25mm
    6 x cables/pipes 0+9.5-32.5mm
    4 x cables/pipes 0+28-54mm
  • External dimensions WxHxD (mm) 463 x 430 x 93.6
  • Aperture dimensions WxH (mm) 278(+5/-5) x 245(+5/-5)
  • Weight (kg)
Add
Remove from cart?

GH BG B FL 100 6x2/52 GALV

  • Configuration 24 x cables/pipes diameter 0+3.5-16.5mm
    16 x cables/pipes diameter 0+10-25mm
    12 x cables/pipes 0+9.5-32.5mm
  • External dimensions WxHxD (mm) 463 x 430 x 93.6
  • Aperture dimensions WxH (mm) 278(+5/-5) x 245(+5/-5)
  • Weight (kg)
Add
Remove from cart?

GH BG B FL 100 6x3/54 GALV

  • Configuration 18 x cables/pipes diameter 0+3.5-16.5mm
    36 x cables/pipes diameter 0+9.5-32.5mm
  • External dimensions WxHxD (mm) 593.5 x 430 x 93.6
  • Aperture dimensions WxH (mm) 409(+5/-5) x 245(+5/-5)
  • Weight (kg)
Add
Remove from cart?

GH BG B FL 100 6x3/57 GALV

  • Configuration 18 x cables/pipes diameter 0+3.5-16.5mm
    24 x cables/pipes diameter 0+10-25mm
    9 x cables/pipes 0+9.5-32.5mm
    6 x cables/pipes 0+28-54mm
  • External dimensions WxHxD (mm) 593.5 x 430 x 93.6
  • Aperture dimensions WxH (mm) 409(+5/-5) x 245(+5/-5)
  • Weight (kg)
Add
Remove from cart?

GH BG B FL 100 6x3/78 GALV

  • Configuration 36 x cables/pipes diameter 0+3.5-16.5mm
    24 x cables/pipes diameter 0+10-25mm
    18 x cables/pipes 0+9.5-32.5mm
  • External dimensions WxHxD (mm) 593.5 x 430 x 93.6
  • Aperture dimensions WxH (mm) 409(+5/-5) x 245(+5/-5)
  • Weight (kg)
Add
Remove from cart?

GH BG B FL 100 6x1/18 AISI316

  • Configuration 6 x cables/pipes diameter 0+3.5-16.5mm
    12 x cables/pipes diameter 0+9.5-32.5mm
  • External dimensions WxHxD (mm) 332.5 x 430 x 93.6
  • Aperture dimensions WxH (mm) 148(+5/-5) x 245(+5/-5)
  • Weight (kg)
Add
Remove from cart?

GH BG B FL 100 6x1/19 AISI316

  • Configuration 6 x cables/pipes diameter 0+3.5-16.5mm
    8 x cables/pipes diameter 0+10-25mm
    3 x cables/pipes 0+9.5-32.5mm
    2 x cables/pipes 0+28-54mm
  • External dimensions WxHxD (mm) 332.5 x 430 x 93.6
  • Aperture dimensions WxH (mm) 148(+5/-5) x 245(+5/-5)
  • Weight (kg)
Add
Remove from cart?

GH BG B FL 100 6x1/26 AISI316

  • Configuration 12 x cables/pipes diameter 0+3.5-16.5mm
    8 x cables/pipes diameter 0+10-25mm
    6 x cables/pipes 0+9.5-32.5mm
  • External dimensions WxHxD (mm) 332.5 x 430 x 93.6
  • Aperture dimensions WxH (mm) 148(+5/-5) x 245(+5/-5)
  • Weight (kg)
Add
Remove from cart?

GH BG B FL 100 6x2/36 AISI316

  • Configuration 12 x cables/pipes diameter 0+3.5-16.5mm
    24 x cables/pipes diameter 0+9.5-32.5mm
  • External dimensions WxHxD (mm) 463 x 430 x 93.6
  • Aperture dimensions WxH (mm) 278(+5/-5) x 245(+5/-5)
  • Weight (kg)
Add
Remove from cart?

GH BG B FL 100 6x2/38 AISI316

  • Configuration 12 x cables/pipes diameter 0+3.5-16.5mm
    16 x cables/pipes diameter 0+10-25mm
    6 x cables/pipes 0+9.5-32.5mm
    4 x cables/pipes 0+28-54mm
  • External dimensions WxHxD (mm) 463 x 430 x 93.6
  • Aperture dimensions WxH (mm) 278(+5/-5) x 245(+5/-5)
  • Weight (kg)
Add
Remove from cart?

GH BG B FL 100 6x2/52 AISI316

  • Configuration 24 x cables/pipes diameter 0+3.5-16.5mm
    16 x cables/pipes diameter 0+10-25mm
    12 x cables/pipes 0+9.5-32.5mm
  • External dimensions WxHxD (mm) 463 x 430 x 93.6
  • Aperture dimensions WxH (mm) 278(+5/-5) x 245(+5/-5)
  • Weight (kg)
Add
Remove from cart?

GH BG B FL 100 6x3/54 AISI316

  • Configuration 18 x cables/pipes diameter 0+3.5-16.5mm
    36 x cables/pipes diameter 0+9.5-32.5mm
  • External dimensions WxHxD (mm) 463 x 430 x 93.6
  • Aperture dimensions WxH (mm) 278(+5/-5) x 245(+5/-5)
  • Weight (kg)
Add
Remove from cart?

GH BG B FL 100 6x3/57 AISI316

  • Configuration 18 x cables/pipes diameter 0+3.5-16.5mm
    24 x cables/pipes diameter 0+10-25mm
    9 x cables/pipes 0+9.5-32.5mm
    6 x cables/pipes 0+28-54mm
  • External dimensions WxHxD (mm) 593.5 x 430 x 93.6
  • Aperture dimensions WxH (mm) 409(+5/-5) x 245(+5/-5)
  • Weight (kg)
Add
Remove from cart?

GH BG B FL 100 6x3/78 AISI316

  • Configuration 36 x cables/pipes diameter 0+3.5-16.5mm
    24 x cables/pipes diameter 0+10-25mm
    18 x cables/pipes 0+9.5-32.5mm
  • External dimensions WxHxD (mm) 593.5 x 430 x 93.6
  • Aperture dimensions WxH (mm) 409(+5/-5) x 245(+5/-5)
  • Weight (kg)
Add
Remove from cart?
Product Configuration External dimensions WxHxD (mm) Aperture dimensions WxH (mm) Weight (kg)
GH BG B FL 100 6x1/18 GALV 6 x cables/pipes diameter 0+3.5-16.5mm
12 x cables/pipes diameter 0+9.5-32.5mm 		332.5 x 430 x 93.6 148(+5/-5) x 245(+5/-5)
GH BG B FL 100 6x1/19 GALV 6 x cables/pipes diameter 0+3.5-16.5mm
8 x cables/pipes diameter 0+10-25mm
3 x cables/pipes 0+9.5-32.5mm
2 x cables/pipes 0+28-54mm 		332.5 x 430 x 93.6 148(+5/-5) x 245(+5/-5)
GH BG B FL 100 6x1/26 GALV 12 x cables/pipes diameter 0+3.5-16.5mm
8 x cables/pipes diameter 0+10-25mm
6 x cables/pipes 0+9.5-32.5mm 		332.5 x 430 x 93.6 148(+5/-5) x 245(+5/-5)
GH BG B FL 100 6x2/36 GALV 12 x cables/pipes diameter 0+3.5-16.5mm
24 x cables/pipes diameter 0+9.5-32.5mm 		463 x 430 x 93.6 278(+5/-5) x 245(+5/-5)
GH BG B FL 100 6x2/38 GALV 12 x cables/pipes diameter 0+3.5-16.5mm
16 x cables/pipes diameter 0+10-25mm
6 x cables/pipes 0+9.5-32.5mm
4 x cables/pipes 0+28-54mm 		463 x 430 x 93.6 278(+5/-5) x 245(+5/-5)
GH BG B FL 100 6x2/52 GALV 24 x cables/pipes diameter 0+3.5-16.5mm
16 x cables/pipes diameter 0+10-25mm
12 x cables/pipes 0+9.5-32.5mm 		463 x 430 x 93.6 278(+5/-5) x 245(+5/-5)
GH BG B FL 100 6x3/54 GALV 18 x cables/pipes diameter 0+3.5-16.5mm
36 x cables/pipes diameter 0+9.5-32.5mm 		593.5 x 430 x 93.6 409(+5/-5) x 245(+5/-5)
GH BG B FL 100 6x3/57 GALV 18 x cables/pipes diameter 0+3.5-16.5mm
24 x cables/pipes diameter 0+10-25mm
9 x cables/pipes 0+9.5-32.5mm
6 x cables/pipes 0+28-54mm 		593.5 x 430 x 93.6 409(+5/-5) x 245(+5/-5)
GH BG B FL 100 6x3/78 GALV 36 x cables/pipes diameter 0+3.5-16.5mm
24 x cables/pipes diameter 0+10-25mm
18 x cables/pipes 0+9.5-32.5mm 		593.5 x 430 x 93.6 409(+5/-5) x 245(+5/-5)
GH BG B FL 100 6x1/18 AISI316 6 x cables/pipes diameter 0+3.5-16.5mm
12 x cables/pipes diameter 0+9.5-32.5mm 		332.5 x 430 x 93.6 148(+5/-5) x 245(+5/-5)
GH BG B FL 100 6x1/19 AISI316 6 x cables/pipes diameter 0+3.5-16.5mm
8 x cables/pipes diameter 0+10-25mm
3 x cables/pipes 0+9.5-32.5mm
2 x cables/pipes 0+28-54mm 		332.5 x 430 x 93.6 148(+5/-5) x 245(+5/-5)
GH BG B FL 100 6x1/26 AISI316 12 x cables/pipes diameter 0+3.5-16.5mm
8 x cables/pipes diameter 0+10-25mm
6 x cables/pipes 0+9.5-32.5mm 		332.5 x 430 x 93.6 148(+5/-5) x 245(+5/-5)
GH BG B FL 100 6x2/36 AISI316 12 x cables/pipes diameter 0+3.5-16.5mm
24 x cables/pipes diameter 0+9.5-32.5mm 		463 x 430 x 93.6 278(+5/-5) x 245(+5/-5)
GH BG B FL 100 6x2/38 AISI316 12 x cables/pipes diameter 0+3.5-16.5mm
16 x cables/pipes diameter 0+10-25mm
6 x cables/pipes 0+9.5-32.5mm
4 x cables/pipes 0+28-54mm 		463 x 430 x 93.6 278(+5/-5) x 245(+5/-5)
GH BG B FL 100 6x2/52 AISI316 24 x cables/pipes diameter 0+3.5-16.5mm
16 x cables/pipes diameter 0+10-25mm
12 x cables/pipes 0+9.5-32.5mm 		463 x 430 x 93.6 278(+5/-5) x 245(+5/-5)
GH BG B FL 100 6x3/54 AISI316 18 x cables/pipes diameter 0+3.5-16.5mm
36 x cables/pipes diameter 0+9.5-32.5mm 		463 x 430 x 93.6 278(+5/-5) x 245(+5/-5)
GH BG B FL 100 6x3/57 AISI316 18 x cables/pipes diameter 0+3.5-16.5mm
24 x cables/pipes diameter 0+10-25mm
9 x cables/pipes 0+9.5-32.5mm
6 x cables/pipes 0+28-54mm 		593.5 x 430 x 93.6 409(+5/-5) x 245(+5/-5)
GH BG B FL 100 6x3/78 AISI316 36 x cables/pipes diameter 0+3.5-16.5mm
24 x cables/pipes diameter 0+10-25mm
18 x cables/pipes 0+9.5-32.5mm 		593.5 x 430 x 93.6 409(+5/-5) x 245(+5/-5)

Configure your own transit kit

Select your set of sealing modules
